HOME > PRODUCTS > Solar Panels > HPBC Solar Module

SE470-500M-54HB ALL BLACK HBC TYPE

INQUIRY
DETAILED SPECIFICATION

Electrical Characteristics(STC/NMOT)


Module TypeSE470M-54HBSE475M-54HBSE480M-54HBSE485M-54HBSE490M-54HBSE495M-54HBSE500M-54HB
Testing ConditionSTC    NOCTSTC   NOCTSTC   NOCTSTC   NOCTSTC   NOCTSTC   NOCTSTC   NOCT
Maximum Power (Pmax/W)470    357475   361480   364485   368490   372495   375500   379
Open-circuit Voltage (Voc/V)40.50   38.4240.63  38.5540.76  38.6740.89  38.8041.02 38.9241.15 39.0441.28 39.16
Maximum Power Voltage (Vmp/V)33.64   31.9233.74  32.0133.84 31.1133.94  32.2034.04 32.3034.14 32.4034.24 32.49
Short-circuit Current (Isc/A)14.82 11.9714.89 12.0314.96 12.0915.03 12.1515.10 12.2115.17 12.2615.24 12.32
Maximum Power Current (Imp/A)13.98 11.1714.09 11.2714.19 11.3514.30 11.4414.40 11.5114.50 11.5914.60 11.67
Module Efficiency -nm(%)2323.323.523.82424.324.5
