STACKABLE TYPE 153.6-512V 100AH SE-SH100-15/50K

INQUIRY

DETAILED SPECIFICATION

Product Description
Product Type	SE-SH100-20K	SE-SH100-30K	SE-SH100-40K	SE-SH100-50K
Number of Modules	4	6	8	10
Battery Capacity	100Ah	100Ah	100Ah	100Ah
Battery Energy	20.48KWh	30.72KWh	40.96KWh	51.2KWh
Size(L×W×H) mm	548×584×1500	548×584×1500	548×584×1950	548×584×2300
Weight	235Kg	384Kg	425Kg	510Kg
Standard Charge Current	20A	20A	20A	20A
Standard Discharge Current	20A	20A	20A	20A
Features
Battery Type	LFP
Cycle Life	≥ 8000 times @ 80% DOD, 25 °C
Nominal Voltage	204.8V	307.2V	409.6V	512V
Operating Voltage Range	160-584V
IP Protection	IP 21
lnstallation	Cabinet Holding
Charging Temperature	0~60℃
Discharge Temperature	-10~60℃
Conventional
BMS Monitoring Parameters	SOC, System voltage,current, cell voltage, cell temperature, PCBA temperature measurement
Communication Port	RS485/RS232/CAN
Waranty	10 Years
