RACK TYPE 314AH 0.5C CHAGRE & DISCHARGE SE-RH314-96/241K

INQUIRY

DETAILED SPECIFICATION


Product Description
Product TypeSE-RH314-96KSE-RH314-128KSE-RH314-160KSE-RH314-193KSE-RH314-209KSE-RH314-225KSE-RH314-241K
Number of Modules681012131415
Battery Capacity314Ah314Ah314Ah314Ah314Ah314Ah314Ah
Battery Energy96.46KWh128.61KWh160.76KWh192.92KWh209.00KWh225.08KWh241.15KWh
Size(L×W×H) mm550×811×2080900×950×1350900×950×1600900×950×1850900×950×1850900×950×2100900×950×2100
Weight830Kg1110Kg1350Kg1600Kg1725Kg1850Kg1975Kg
Standard Charge Current157A157A157A157A157A157A157A
Standard Discharge Current200A200A200A200A200A200A200A
Features
Battery TypeLFP
Cycle Life≥ 8000 times @ 80% DOD, 25 °C
Nominal Voltage307.2V409.6V512V614.4V665.6V716.8V768V
Operating Voltage Range268.8-864V
IP ProtectionIP 21
lnstallationCabinet Holding
Charging Temperature0~60℃
Discharge Temperature-10~60℃
Conventional
BMS Monitoring ParametersSOC, System voltage,current, cell voltage, cell temperature, PCBA temperature measurement
Communication PortRS485/RS232/CAN
Waranty10 Years
