WALL-MOUNTED 48/51.2V 100/200AH SE-WL-5/10K

INQUIRY

DETAILED SPECIFICATION

Model	SE-WL-5K	SE-WL-10K
Voltage	48/51.2V
Capacity	100Ah	200Ah
Battery Cell	3.2V 100Ah Prismatic Battery Cell
Configuration	15S/16S 1P	15S/16S 2P
Parallel Capacity	Yes, 16 units maximum
Max. Charge Current	100A
Max. Discharge Current	100A
Discharge Cut-off Protect Voltage	42V/44.8V
Charge Cut-off Protect Voltage	54V/57.6V
Cycle life	8000 Cycles @80% DoD
Communicate Port	CAN, RS485, RS232
L×W×H(mm)	680×485×180(220)mm
Weight(KG)	68Kg/72Kg	98Kg/106Kg
Discharge Temperature(℃)	-20~50℃
Charge Temperature(℃)	0~55℃
Lithium Battery Standard	IEC62619/CE/UN38.3/IEC61000 /ROHS/MSDS

COMPATIBLE INVERTERS
